TL725D RS232 / RS485 ANGULAR RATE SENSOR FOR AUTOMATIC AGRICULTURAL MACHINERY

Name: TL725D RS232 RS485 ANGULAR RATE SENSOR FOR AUTOMATIC AGRICULTURAL MACHINERY
Brand: Rion
Price: 60.00 USD

China TL725D RS232 / RS485 ANGULAR RATE SENSOR FOR AUTOMATIC AGRICULTURAL MACHINERY wholesale

Brand Name : Rion

Model Number : TL725-485

Certification : CE, ISO

Place of Origin : Guangdong, China

MOQ : 1

Price : $60.00/Pieces >=1 Pieces

Payment Terms : T/T,Paypal

Supply Ability : 3000 Piece/Pieces per Month

Delivery Time : 7 days for samples

Packaging Details : 1pcs/box with sponge inside, 100pcs/ctn

Usage : agricultural vehicle auto driving

Bandwidth : >100Hz

Nonlinear : 0.1% of FS

Startup time : 500ms

Input voltage : +9~36V

Connector : RS232 / RS485 / (Optional)

Contact Now

TL725D RS232 / RS485 ANGULAR RATE SENSOR FOR AUTOMATIC AGRICULTURAL MACHINERY

▶PRODUCT DESCRIPTION
TL725D is a gyroscope IMU designed for agricultural vehicle auto-driving. Equipped with industrial-grade 3-axis gyroscope and accelerometer, it delivers stable attitude data even under strong vibration. Based on a MEMS inertial platform with dynamic attitude algorithm, it outputs real-time inclination, azimuth, angular rate, acceleration, and forward-axis acceleration. With Z-axis integral counting output, it ensures accurate front-wheel steering. TL725D is a key component for next-generation precision farming machinery.

▶ FEATURE

★ Attitude angle & azimuth output

★ Real-time angular rate
★ Forward-axis acceleration

★ Long life & stability
★ Compact, lightweight, solid-state

★ DC 9~36V supply

▶APPLICATION

★ Automated agricultural machinery

★ Precision farming
★ Combine harvesters

★ Farming vehicles

PRODUCT SPECIFICATIONS

TL725D		PARAMETERS
Three-axis attitude		Azimuth ±180°, Roll angle±180°, Pitch angle±90
Bandwidth		>100Hz
Nonlinear		0.1% of FS
Three-axis gyroscope	Gyro Range	250°/s
	Angle random walk coefficient (allan)	0.25°/sqrt(h)
	Bias stability mg (10s smooth)	8.5°/h
Three-axis acceleration	Range	±4g
	Resolution	0.001g
	Accuracy	1mg
	Bias instability°/h (allan)	0.05mg
	Speed random walk coefficient (allan)	0.015m/s/sqrt(h)
	Bias stability°/h(10s average)	0.15mg
Startup time		500ms
Input voltage		+9~36V
Current		35mA(12V)
Working temp.		-40 ~ +80℃
Storage temp.		-40 ~ +85℃
Vibration		5g~10g
Shock		200g pk, 2ms, ½sine
Working life		10 Year
Output frequency		1Hz~200Hz Settable
Output signal		RS232 / RS485 / (Optional)
MTBF		≥98000 Hours/times
Insulation resistance		≥100MΩ
Shockproof		100g@11ms/3 Axial Direction (Half Sinusoid)
Anti-vibration		10grms/10～1000Hz
Protection grade		IP67
Cable		Standard 1 m 4 pin shield wire
Weight		≤160g (including 1 meter cable)

● PRODUCTION INSTALLATION NOTES

1.The installation surface of the angle instrument should be kept parallel to the measured target surface and the influence of dynamic and acceleration on the angle instrument should be reduced. Incorrect installation can cause measurement error, Pay particular attention to 1 "face" and 2 "lines ":1)The mounting surface and the measured surface must be fixed tightly, flat and stable. If the mounting surface is uneven, it is easy to cause the angle error of the IMU gyro measurement.

2)The angle axis must be parallel to the measured axis, and the two axes can not produce an angle.

2.Do not shake the product violently during use, avoid violent vibration during use, and stay away from the source of vibration (if unavoidable, please install a shock absorber), so as not to affect the product measurement accuracy;

3.During use, try to avoid movements with angular velocity greater than 300°/s, such as rapid acceleration, sudden stop, and sharp turning, so as not to affect the product measurement accuracy.
